Siemens GSD341.1A Damper Actuator
Siemens GSD341.1A Damper Actuator
| Structure | Control |
| Valve Motion | Rotary Motion Valve |
| Model Name/Number | GSD341.1A |
| Brand | Siemens |
| Rated Load | 250 lb |
| Stroke Length | Rotary type |
| Retracted Length | Rotary |
| Power Supply | 230 V Ac / 24 V Ac |
| Damper Area | 3 Sq meter |
| Running Time | 150 Sec |
Rotary actuator for air dampers with an area of up to 0.3 m2, depending on friction. For direct control of zone dampers to regulate the air flow in the air duct. The drive can be used in combination with controllers.
Properties:
- power supply 230 VAC
- torque 2 Nm
- rotation angle 90 °
- adjustment time 30 s
- dimensions 121.4 mm (l) x 70 mm (w) x 62.5 mm (h)
- 2-, 3-point control
Advantages:
- very fast small actuator with an adjustment time of 30 s
- robust cover
- self-centering adapter for all shaft profiles
- compact design - easy installation
- color-coded numbered cables
- maintenance free gears
- Silent
- overload resistant
- no position switch required
Additional Information:
- Delivery Time: Ready Stock available
